vacuum forming machine(Six stations) ,shoe vacuum heat setting machine

Device display
  • Equipment details
  • VACUUM FORMING MACHINE ,shoe vacuum heat setting machine

    no1.Steam spray device is adopted to wet the shoes uppers which later should be

     dried up by rapid neating before being shaped and rubbed by vacuum system.

    no2.Different temperature for toe tip and heel could be adjusted due to different material

    and reaches the best result,vacuum processing period is 3-5 mins.

    no3.The lasts and shoes be well fitted in the vacuum and which resulted in more everlasting shape of shoes.

    no4.For saving time.upgrading productivity and consistant quality.

    no5.To enhence the productivity and to stablize the quality.

    Technical specifications:



    MODEL

    DimensionsL*W*H

    PRODUCTION

    N.W

    VOLTAGE

    POWER

    DF-906

    4800*1520*2020mm

    300pairs/8jrs

    2290kg

    380V/50Hz

    32KW
